Assistive Product Zimmerrollstuhl RZ-Mini

Product Type:

Manually controlled wheelchair for indoor use

Description:

The RZ-Mini wheelchair is a manually controlled wheelchair for domestic use that has high-swinging armrests and is available in various model versions.

Features / Components:

  • Frame: Steel, conical chassis, rigid
  • Push bar
  • Back: removable backrest, upholstered
  • Seat: upholstered
  • Armrests: swivel up
  • Legrests: fixed to chassis, rigid
  • Footrests: split, height adjustable, fold up
  • Drive: push rim drive
  • Tires: drive wheels: puncture-proof tires; steering wheels: puncture-proof tires
  • Brake: tire brake / parking brake
  • Other: wheel cover, tipping aid
  • Color: frame: gray-alu, cover: anthracite, blue, magenta, red, black

Price (without guarantee):

Prices are available on request from the manufacturer / distributor.

Product Information from the Manufacturer / Distributor:

Further Product Details

Further Information

REHADAT does not sell any products

Please contact the manufacturer or distributor.

Manufacturer:

Rollstuhlbau Bräunig
Schongauerstr. 23
04328 Leipzig
Germany Telephone: 0341 26124-38 Email: info@braeunig-rollstuehle.de Homepage: https://www.braeunig-rollstuehle.de/ Homepage: https://www.zimmerrollstuhl.de/

Distributor:

Rollstuhlbau Bräunig
Schongauerstr. 23
04328 Leipzig
Germany Telephone: 0341 26124-38 Email: info@braeunig-rollstuehle.de Homepage: https://www.braeunig-rollstuehle.de/ Homepage: https://www.zimmerrollstuhl.de/

Sanitätsfachhandel
Örtliche Sanitätshäuser und Orthopädie-technische Fachbetriebe
Homepage: https://biv-ot.org/ueber_uns/mitglieder/sanitaetshausdatenbank/index_ger.html

Technical Data:

Overall width: 51 cm (standard; SB 40 cm); 56 cm (SB 46 cm)
Overall height: 93 cm
Overall length: 98 cm (standard); 72 - 98 cm (depending on variant)
Seat width: 40 cm (standard); 46 cm (surcharge)
Seat depth: 44 cm
Seat height: 53 cm
Drive wheels: Ø 20 x 1⅜ inch
Steering wheels: 150 mm x 32 mm
Weight: 17.4 kg (standard); from 15.9 kg (depending on variant)
Load capacity: 100 kg

Options / Accessories:

The standard version of the RZ-Mini can be supplemented and modified with accessories. This results in the following model variants:

Variant for people with leg amputations on both sides:
  • Leg supports: connected by a metal bracket
  • Other: anti-tip castor (adjustable)
Multi-purpose variant:
  • Frame: widened at the front
  • Drive: hemi wheelchair
  • Brake: adjustable
  • Other: anti-tip castor (adjustable), suitable for users after a leg amputation
Variant with foot swivel bracket:
  • Frame: widened at the front
  • footrest: swiveling (length of the wheelchair can be shortened by 22 cm)
Variant with removable leg supports:
  • leg supports: removable
  • footrests: divided, foldable
Variant with toilet seat:
  • Seat: plug-in seat (removable, padded)
  • Other: built-in toilet seat, toilet tank (can be pulled out to the front)

The installation of the toilet equipment is possible with all variants of the RZ-Mini.

ICF Items

Reference Number:

IW/122203.025


Source :

IW


Last Update: 22 Mar 2023
