Assistive Product Avantgarde 4 DF Version S | Avantgarde 4 DF Version V

Product Type:

Manually controlled wheelchair, foldable
Adaptive wheelchair

Description:

The Avantgarde 4 DF wheelchairs versions S and V are foldable adaptive wheelchairs. They have various adjustment options. The Avantgarde 4 DF version V wheelchair has swing-away leg supports so that it can be used as a hemi wheelchair. The wheelchairs are suitable for transporting people in vehicles (crash-tested).

Features / Components:

  • Frame: Aluminum frame, foldable, double cross brace, selectable front frame crank
  • Push handles: short / long
  • Back: adjustable backrest upholstery; backrest: height-adjustable, selectable height, straight / with lumbar bend
  • Seat dimensions: selectable seat width, selectable seat depth, selectable seat height, height-adjustable, depth-adjustable, width-adjustable
  • Side parts: Aluminum
  • Legrests: swing-away (version V), fixed (version S)
  • Footrest: split, short / medium / long / extra long
  • Drive: push rim drive
  • Push rims: Attachment narrow / wide
  • Wheels: selectable wheel sizes
  • Tires Steering wheels: solid rubber tires, pneumatic tires ; Drive wheels: PU tires, pneumatic tires
  • Brake: knee lever brake
  • Other: quick-release axle, crash-tested
  • Color: frame: various colors ; Color steering wheel fork: various colors

Price (without guarantee):

Avantgarde 4 DF Version S: EUR 2,840.00
Avantgarde 4 DF Version V: EUR 2,890.00

The prices are recommended retail prices plus VAT.

SHI-Number:

| 18.50.03.0262 | 18.50.03.0263

Product Information from the Manufacturer / Distributor:

Further Product Details

REHADAT does not sell any products

Please contact the manufacturer or distributor.

Manufacturer:

Otto Bock Manufacturing Königsee GmbH
Lindenstr. 13
07426 Königsee
Germany Telephone: 036738 79-0 Homepage: https://www.ottobock.de

Distributor:

Otto Bock HealthCare Deutschland GmbH
Max-Näder-Str. 15
37115 Duderstadt
Germany Telephone: 05527 848-0 Email: digitalesmarketing@ottobock.de Homepage: https://www.ottobock.de

Technical Data:

Overall width: 49 - 72.5 cm
Overall height: 58 - 110 cm
Seat width: 32 / 34 / 36 / 38 / 40 / 42 / 44 / 46 / 48 / 50 / 52 cm
Seat depth: 36 / 38 / 40 / 42 / 44 / 46 / 48 / 50 / 52 cm
Seat height (front): 39 - 55 cm
Seat height (rear): 36 - 51 cm
Back height: 25- 32.5 / 32.5 - 40 / 42.5-50 / 52.5 - 55 cm (straight); 35 - 40 / 40 - 45 / 45 - 50 / 50 - 55 cm (with lumbar bend)
Swivel wheels: 4 / 5 / 5.5 / 6 / 7 inches
Drive wheels: 22 / 24 / 25 inches ; 26 inches (On request)
Camber: 0 / 2 / 3 / 4 degrees
Weight: 8.7 kg (version S), 9.7 kg (version V)
Load capacity: 140 kg

Options / Accessories:

  • Frame: Single cross strut
  • Push handles: telescopic, height-adjustable, removable, foldable
  • Back: breathable / ultra-light backrest cover; backrest: angle-adjustable, foldable
  • Seat: various seat cushions
  • Side parts: with cold protection (version V), aluminum (version S)
  • Armrest: padded, swivel
  • Legrests: removable, amputee leg supports (version V), continuous / divided, angle-adjustable
  • Footrest: aluminum, one-piece
  • Wheels: wheelbase extension
  • Tires Steering wheels: soft roller ; tread Drive wheels: Schwalbe Marathon Plus Evolution, Schwalbe One 1
  • Drive: one-hand drive
  • Push rims: Double handrims, rubberized, stainless steel, Curve L / Curve L Grip, Gekko, handrim cover
  • Brake: Brake lever extension fixed / plug-in, scissor brake, one-hand operation for knee lever brake, drum brake for accompanying person
  • Other: Transit rollers, tipping aid, anti-tipper, stabilizing bar, active lighting
  • Colours: Frame: Special colors
SHI-assistive product numbers:
Avantgarde 4 DF Version S: 18.50.03.0262
Avantgarde 4 DF Versoin V: 18.50.03.0263

ICF Items

Reference Number:

Hil136999


Source :

IW


Last Update: 18 Dec 2024
